LED Moving Head Beam
LED Moving Head BeamLED Moving Head Beam

LMHB-150A5(CW)B

LED Moving Head Beam, 150W,Cool White,3°,IP20,Black Shell

Categories: .

Source
•Leds: 1pc COB 150W cool white + 24×0.2w RGB 3IN1
•LED Life Expectancy: Minimum 50.000 hours
•Drive Mode: Constant Current

Optics
•Beam Angle: 3°
•Color temperature: 9000K
•CRI (Ra>): 77
•Dimmer: 0-100%
•Strobe: 0-20Hz

Gobo Wheel
•1pc static gobo wheel: 8 metal gobos + white, wheel rotation and shake
•1pc rotating gobo wheel: 6 metal gobos + white, wheel rotation and shake

Control and programming
•Control Mode: DMX, autorun, Master/Slave, Sound-activate
•Control Channels: 19/17CH
•Display: LCD

Power Supply:
•Power supply: Electronic auto-ranging
•Power Input Rating: 100-240 V AC, 50-60 Hz
•Power consumption: 190W
•Power Connectors In/Out Powercon

Data Connection:
•Data Connectors In/Out: XLR 3Pin (XLR 5Pin is optional)
•Wirelss DMX Data In: XLR 5Pin (XLR 3Pin optional)

Body
• Housing: die-cast flame retardant plastic
• Housing color: black (white optional)
• Housing surface treatment: baking finished

Safety Devices
• Power failure memory
• Electronic protection against short circuit

Work Enviroment
•Enviroment temperature: -25 °C -40 °C

Cooling System
• Thermal management system ensures long life of LEDs
“• Automatic reduce brightness in case of overheating

“• Heatsinks in aluminum

“• Cooling for head: forced air convection with 1 fan

“• Cooling for base: forced air convection with 1 fan

“• Cooling fan speed auto change according to temperature

“• Cooling fans auto start once internal temperature reach 45º

Internal protection
• IP rating: IP20

Mechanical Specification
•Length: 300 mm
•Width: 204 mm
•Height: 445 mm
•Weight: 12.0 kg

Approval:
•CE

Accessories
• Power input cable included, length 1.2mtr
• Power cable: 0.75mm2, PVC
• DMX cable not included (optional)

• Safety cable not included (optional)

• Hanging bracket included (2pcs/pair)
