Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 500W
Optics
▪ 1296X0.4W RGBW(4IN1)SMD
▪ Beam angle: 120°
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
Color System
▪ Color Mixing: RGBW(4IN1)
Effects
▪ Strobe: 0-30Hz
▪ Dimming : 0% – 100% (16-bits dimming)
▪ Variable Dimming Curves
▪ 12-segment pixel control, with 81 LED chip per segment
▪ White color temperature: 6500K
Control and Programming
▪ Protocal: DMX 512 (RDM, Artnet optional)
▪ DMX channels: 8/12/64
▪ Control Modes: DMX, Master/Slave, Auto Run
▪ Display: LCD
Connections
▪ Data in/out:3-pin（5-pin XLR optional)
▪ Power in/out: PowerCon
Cooling System
▪ Cooling: Silent fan
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Aluminum diecast
▪ Color: Matte Black
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 868 mm
▪ Width: 85 mm
▪ Height: 158 mm
Weight
▪ Weight: 6.0 kgs
Accessories
▪ Power input cable included, length 1mtr
▪ DMX cable included, length 1mtr
▪ Safety cable not included (optional)
Approvals
▪ CE
