ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Beam angle: 4°-35°
▪ Power consumption: 1000W
OPTICS
▪ Light Source: 27X40W RGBW 4in1
▪ Lens：high brightness reflector
COLOR SYSTEM
▪ Color Mixing: RGBW (4IN1)
▪ CTO
EFFECTS
▪ Strobe effect：0-20HZ strobe、Pulse strobe、Ramp up strobe、Ramp down strobe、Random strobe、Strobe Break Effect, 5s…..1s、Strobe0-20Hz
▪ Dimmer:0-100% 16bit dimming, capable of simultaneously controlling the brightness and dimming of four colors, and each LED can be individually controlled in three segments
▪ Each LEDs can be controlled in 4colors
▪ Dimming way：LED mode and Halogen lamp mode
CONNECTIONS
▪ Power In/Out: waterproof powerCON IN / OUT
▪ DMX input：waterproof 3 Pin XLR input
▪ DMX output：waterproof 3 Pin XLR output
CONTROL
▪ 6 DMX channel modes: 4/5/7/13/16/28 channel modes
▪ 3 control modes: DMX512, master-slave, WDMX
DISPLAY
▪ 2.4-inch TFT color display screen
▪ High anti-interference four touch buttons
▪ Keylock can be set to prevent accidental operation
▪ The display board can reverse 180 °, suitable for installation in different positions
SOFTWARE
▪ Software upgrade：Update via DMX link
▪ Display the usage time of the lighting fixtures, making it convenient for customers to timely understand the usage of the lighting fixtures
COOLING SYSTEM
▪ Cooling: Fan cooling(the fan change the speed with the temperature changes）
▪ LED temperature detection system to protect the lifespan of lamp beads
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): 5° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
QUALIFICATIONS
▪ IP Rating: IP65 (outdoor use)
CONSTRUCTION / PHYSICAL
▪ Dimensions: 62.2×22.8×10.3 cm
▪ Weight (single unit):20.5 kg
▪ Exterior Color: Black
▪ Housing Material: Aluminum die-cast
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1pc
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
