Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 350W
Optics
▪ LEDs: RGB 120X3W, W 120X1W， A 120X1W
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
Color System
▪ Color Mixing: RGBWA 5IN1
Effects
▪ Strobe: 0-30Hz
▪ Dimming : 0% – 100% (16-bits dimming)
▪ Variable Dimming Curves
Control and Programming
▪ Protocal: DMX
▪ DMX channels: 9 CH
▪ Built-in programs
▪ Display: LED
▪ Control mode：DMX512
Connections
▪ Data in/out:3-pin（5-pin XLR optional)
▪ Power in/out: fixed
Cooling System
▪ Cooling: entire casing as heat sink, Natural convection cooling
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Aluminum diecast
▪ Color: Matte Black
▪ Protection rating: IP65
Mechanical Specification
▪ Length: 1012 mm
▪ Width: 150 mm
▪ Height: 319 mm
Weight
▪ Weight: 9.5 kg
Accessories
▪ Power input cable included, length 1mtr
▪ DMX cable included, length 1mtr
▪ Barndoor not included (optional)
▪ Safety cable not included (optional)
