Electrical
▪ Input voltage: 100-240 V AC, 50-60 Hz
▪ Max. power consumption: 400 W
Optics
▪ Light source: 36x 10W RGBW 4in1 LED
▪ Led Life Expectancy: minimum 50.000 hours
▪ Beam Angle: 15°–50°
Photometric Data
▪ Strobe: 1-20/second
▪ Electronic dimming: 0 – 100%, four dimming curve options
Color
▪ Beam color mixing: RGBW
Effects
▪ Led rainbow effect
▪ Led macros effect
▪ Zoom: 15°–50°
▪ Pan: 540°
▪ Tilt: 240°
▪ Pan/Tilt Resolution: 16 bit
▪ Pan and tilt speed: Adjustable via onboard control panel and DMX
Control and Programming
▪ Control system: DMX, Auto, Sound Activated,Master-slave
▪ Control resolution: 16-bit control of pan & tilt
▪ DMX channels: 14
▪ Setting and addressing: Control panel with backlit graphic display
▪ DMX compliance: USITT DMX512-A
Connections
▪ Data in/out:3-pin ( 5-pin XLR optional)
▪ Power in/out: PowerCon
Thermal
▪ Cooling: Automatically adjust cooling-fan
▪ Maximum ambient temperature (Ta max.): 40° C (104° F)
▪ Minimum ambient temperature (Ta min.): 5° C (41° F)
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Color: Black
▪ Housing: module pressing high strength alloy
▪ Protection rating: IP20
Weight and dimensions
▪ Net Weight: 12.0 kg
▪ Dimensions (WxHxD): 400x300x430 mm
Accessories
▪ Power input cable included, length 1.2mtr
▪ DMX cable included, length 1.5mtr
▪ 2x Omega brackets for fast and comfortable lock
▪ Safety cable included, length 0.65mtr
Approvals
▪ CE
