Optical
▪ Light source:19x15W RGBW LED, uniform and delicate color mixing effect
▪ Beam Angle:7°-58°
Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 250W
▪ Power factor: 0.96
Color System
▪ Color Mixing: RGBW (4IN1)
Effects
▪ Strobe: 1-20 flashes/sec.
▪ Dimming : 0-100% linear
▪ Uniform RGBW color mixing system and rainbow effect
▪ White balance can be adjusted manually
Control and Programming
▪ Control Mode: DMX512, voice control, master-slave
▪ DMX channels: 6CH/9CH
▪ DMX compliance: DMX512
▪ Display: LCD
Connections
▪ Data in/out:3-pin （5-pin XLR optional)
▪ Power in/out: PowerCon
Cooling System
▪ Cooling: forced air convection, with 1pc slient fan (temperature-regulated, low noise, user-definable levels)
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 60° C
▪ Minimum ambient temperature (Ta min.): -40° C
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: Aluminum + Metal
▪ Color: black (white optional)
▪ Housing surface treatment: metal baking finished
▪ Protection rating: IP20
Mechanical Specification
▪ Length: 298 mm
▪ Width: 246 mm
▪ Height: 360 mm
Weight
▪ Weight:6.1kg
Accessories
▪ Power input cable included, length 1.4mtr
▪ DMX cable not included (optional)
