LIGHT SOURCE
LEDs: 9pcs 15W, RGBWA+UV 6in1
Color temp of white LED: 7000-7200K
CRI: Ra>72
Luminous flux: Max. 3,180 lm
Drive mode: constant current
4Drive current: 400mA
OPTICS
Beam angle: 25° (15° , 45° optional)
Light ouput (full Bright): @25°: 510Lux@4mtr
Optic lens: acrylic, effective diameter 40mm
DIMMER & STROBE
Electronic dimming: 0-100% linear, 16bit smooth dimming
Refresh rate: >3K Hz (Flicker free) , suitable for TV applications and all video recorded events
Electronic strobe: 1-20 flashes/sec.
Built-in strobe macro: Built-in strobe macro and speed adjustable
EFFECTS
Built-in color macro: color fade in & out; color jumping
Built-in Demo: 9 auto run programmes, speed adjustable
CONTROL MODE
Control protocol: DMX512
Control mode: DMX, Wireless, IR remote, Autorun, Master/Slave, Sound-activate
DMX channels: 6/10CH
DMX data In/Out: XLR 3Pin (XLR 5Pin optional)
DISPLAY & MENU SETTING
Display: color LCD backlit
Setting and addressing: via 4-menu-button
Menu language: English
PAN-TILT
Tilt (support bracket): ±180º
POWER SUPPLY
Power supply: AC100V-240V; 50/60Hz
Power consumption: Max. 42W
Battery: lithium, 18650, DC12.5V
Battery group capacity: 10,000mAh
Fixture working time: 4 hours @full power; 15 hours @auto mode; 20 hours @single color
Battery charge time: 4 hours
Power In/Out: waterproof, Powercon daisy chain
COOLING
Heat sink: Entire casing as heat sink
Cooling: natural convection (no fan, no noise)
SAFETY PROTECTION
Electrical protection: Electronic protection against short circuit
Isolating protection: Input signal isolating protection
RIGGING & MOUNTING
Mounting bracket: 1pc
ENVIRONMENT AND PHYSICAL
IP rating: IP65
Dimensions(mm): W150 x D100 x H180
Dimensions(inch): W5.90 x D3.94 x H7.09
Net weight: 3.6kg (7.94lb)
ACCESSORIES
Power input cable: included, length 1.2mtr
DMX cable: not included (optional)
Infrared remote controller: W5.90 x D3.94 x H7.09
Safety cable: not included (optional)
