LIGHT SOURCE
LEDs: COB 600W, WW+CW 2IN1
Color temp: 3000K – 6000K
Color rendering index(CRI): Ra>90
LEDs average lifespan: >50,000hrs
Drive mode: constant current
OPTICS
Beam angle: 25°-50°
Flicker free (refresh rate >100K Hz)
COLORS
Color Mixing: WW+CW 2IN1
EFFECTS
16 bit smooth dimming
Electronic dimmer: 0-100% linear
Electronic strobe: 1-25 flashes/sec.
CONTROL AND PROGRAMMING
DMX Channel: 2CH
BODY
Housing: Die-Cast Aluminum
Housing color: black (white optional)
Housing surface treatment: baking finished
POWER SUPPLY
Power consumption: Max. 650W
Auto switching power supply unit
Power supply: AC100V-240V, 50/60Hz (auto-ranging)
COOLING & THERMAL MANAGEMENT
Cooling system: No noise fan (copper tube)
SAFETY DEVICES
Power failure memory
Electronic protection against short circuit
RIGGING
With single mounting yoke
ENVIRONMENT AND PHYSICAL
IP rating: IP20
Environment temp: -20°C-45°C
Dimensions(mm): L820 x W330 x H315 (with yoke)
Net weight: 11.0 kgs
ACCESSORIES
• Gel frame(i.e. filter frame) included
• Gobo holder included
• DMX cable included
• Power input cable included, length 1.2mtr
• Power cable: 0.75mm2, PVC
• Safety cable not included (optional)
• Manual iris not included (optional)
