ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Color Temperature : 6500K
▪ Beam Angle: 5-55°
▪ Power consumption: 1510W
OPTICS
▪ Light Source: 7X180W RGBW 4IN1+60 x 4W RGBW LED
▪ Drive Mode: Constant Current
COLOR SYSTEM
▪ Color Mixing: RGBW 4in1
MOVEMENT
▪ Pan/Tilt movement：: Pan : 540° ,Tiit : 250°
▪ Automatic position correction after step loss
▪ 16-bit
DYNAMIC EFFECTS
▪ Strobe effect：1-25HZ with multiple strobe effects
▪ Dimming：Smooth 0–100% dimming with various strobe effects at different speeds
▪ 4 dimmer curves
▪ Halo Effect: Creates ultra-soft wash coverage. Multiple built-in macros control foreground/background colors, speed and direction
▪ Features high-end car taillight-style flowing circular halo trails.
▪ Color: RGBL color mixing presents ultra-bright, vivid saturated colors, soft pastel tones and white shades, with a dynamic virtual color palette.
CONSTRUCTION / PHYSICAL
▪ Dimensions: 431X298X612mm
▪ Weight (single unit):26.0kgs
▪ Exterior Color: Black
▪ Housing Material: Aluminium Die Casting
▪ Display: LED screen
CONNECTIONS
▪ Power In/Out: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 3pin (5pin optional)
CONTROL
▪ Control Protocol: DMX512，Auto，RDM, Support for Art-Net,wireless signal reception
▪ DMX Channels: 29CH/56CH/137A CH/137B CH
COOLING SYSTEM
▪ Cooling: with 2 slient fan,fans’ speeds adjustable
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
CERTIFICATIONS / QUALIFICATIONS
▪ CE
▪ IP Rating: IP65 (outdoor use)
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1pc
▪ Hanging omega bracket included (2pcs/pair)
▪ Safety cable excluded
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
