LED Profile Spot Ellipsoidal
LED Profile Spot EllipsoidalLED Profile Spot EllipsoidalLED Profile Spot EllipsoidalLED Profile Spot EllipsoidalLED Profile Spot EllipsoidalLED Profile Spot Ellipsoidal

LPSE-170A1(4IN1)B-36

LED Profile Spot Ellipsoidal , 170W, RGBW 4IN1, 36°, 9CH, IP20, Black Shell

Source
• Leds: 1X170W COB
• LED Life Expectancy: Minimum 50.000 hours
• Drive Mode: Constant Current

Optics
• Beam Angle: 36º
• Flicker free (refresh rate >4K Hz)
• Color rendering: >69Ra
• Color Temperature: 3000K-6500K

Effect:
• Electronic dimmer: 0-100% linear
• Electronic strobe: 1-25 flashes/sec.

Control and programming
• Control mode: DMX, autorun and Master/Slave
• Control Channels: 9 CH
• Display: LCD

Power Supply:
• Power supply: Electronic auto-ranging
• Power Input Rating: 100-240 V AC, 50-60 Hz
• Power consumption: 190 W
• Input/Output Power connections: Powercon
• Input/Output Signal connections: 3p XLR ( 5p XLR optional)

Body
• Housing: ABS engineer plastic
• Housing color: black (white optional)
• Housing surface treatment: baking finished

Safety Devices
• Power failure memory
• Electronic protection against short circuit

Work Enviroment
• Enviroment temperature: -25 °C -40 °C

Cooling System
• Cooling: forced air convection, with 1 slient fan

Internal protection
• IP rating: IP20

Mechanical Specification
• Length: 660 mm
• Width: 360 mm
• Height: 360 mm
• Weight: 6.4 kg

Approval:
• CE

Accessories
• Gel frame(i.e. filter frame) included
• Gobo holder included
• Manual iris not included (optional)
• Power input cable included, length 1.0mtr
• Power cable: 0.75mm2, PVC
• DMX cable included, length 3mtr
• Safety cable not included (optional)
