Electrical
▪ AC power: 100-240 V nominal, 50/60 Hz
▪ Typical total power consumption: 160 W
Optics
▪ Light source: 54pcs 3W, 42 warm white+12 cool white
▪ Beam Angle：25º (40ºoptional)
▪ Minimum LED lifetime: 50 000 hours (to >70% luminous output)
Dynamic Effects
▪ Electronic dimming: 0-100% linear
▪ 16bit smooth dimming
▪ Electronic strobe: 1-20 flashes/sec
▪ Built-in color fade in & out macro, speed adjustable
▪ Built-in color jumping macro, speed adjustable
Control and Programming
▪ Control options: DMX
▪ DMX channels: 4CH
▪ Control mode: DMX, master/slave, auto, sound-activate
▪ Onboard programming enables programming without external DMX controller
Construction
▪ Housing: die-cast aluminium
▪ Color(s): Black
▪ Protection rating: IP20
Installation
▪ Mounting: Double bracket, surface or truss mount
▪ Orientation: Any
▪ Location: Indoor use only
Connections
▪ AC power in/thru: PowerCon
▪ DMX data in/thru: 3-pin XLR (5-pin XLR Optional)
Thermal
▪ Cooling: forced air convection, with 1 slient fan
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
Physical
▪ Length: 305 mm
▪ Width: 305 mm
▪ Height: 185 mm
▪ Weight: 3.82 kg
Accessories
▪ Power input cable: 0.75mm2, length 1.5mtr
▪ Power cable sheath material: PVC
▪ DMX cable included, length 2mtr
▪ Safety cable not included (optional)
