LIGHT SOURCE
● Lamp: Platinum SIRIUS HRI 200W, brand OSRAM
● Color temp: 8000K
● CRI: Ra=80
● Luminous flux: Max. 10,200 lm
● Lamp average lifespan: 2,000hrs
OPTICS
● Beam angle: 3°
● Light ouput (full right): 51,930Lux@12mtr
● Optic lens:
Multi-set high precision optical Lens
High quality optic system make super brightness
DIMMER & STROBE
● Mechanical dimming: 0-100% linear, dual shutter
● Mechanical strobe: 1-15 flashes/sec.
EFFECTS
● Focus: Electronic linear focus
● Frost: 0-100% linear, single shutter
● Frost angle: 50°
● Built-in : 15 effects macro; 2 auto run programmes
COLOR WHEEL
● Color wheel:
14 dichroic colors + open
Rainbow effect at variable speeds in bi-directions
with two semi-colors function
● Color change: 0-100% linear
● CTO filters: 3200/6000/10000K (on color wheel)
STATIC GOBO WHEEL
● Static Gobo wheel:
17 gobos + open
6 levels beam aperture adjustment
Gobo flow at variable speeds in bi-directions
Gobo shake at variable speed
PRISM
● 16-facet circular prism
● indexable, bi-directional rotation at variable speed
CONTROL MODE
● Control protocol: DMX512
● Control mode: DMX, Master/Slave, Autorun, Sound-activate
● DMX channels: 16CH
● DMX data In/Out: XLR 3Pin (XLR 5Pin optional)
DISPLAY & MENU SETTING
● Display: 2.0inch blue LCD backlit
● Display flip: with flip function (can be rotate through 180°)
● Setting and addressing: via 5-menu-button
● Menu language: English/Chinese
PAN-TILT
● Pan: Max 540°, with 8 or 16 bit resolution
● Tilt: Max 270°, with 8 or 16 bit resolution
● Pan/Tilt: automatic Pan/Tilt reposition
● Pan/Tilt motors: 2 phase
● Locking mechanisms: Tilt locking mechanisms
BODY & HOUSING
● Housing: ABS engineer plastic and iron
● Housing surface: baking finished treatment
● Housing color: black (white optional)
POWER SUPPLY
● Power supply: AC100V-240V; 50/60Hz
● Power consumption: Max. 260W
● Power Supply Unit (PSU): 350W, PFC>0.98
● Power In: blue powercon
● Save power: Automatically save 60W lamp power when fixture blackout
COOLING
● Cooling: forced air convection
● Cooling for light source: 2 fans +1 blower
● Cooling for base: 2 fans
THERMAL MANAGEMENT
● Over temperature protection (110ºC)
● Auto switch off light source in case of overheating
● Thermal sensor monitors the lamp ignition and ensures the fixture works at proper temperature
SAFETY PROTECTION
● Fuse: 5A 120V, 3.15A 240V
● Electrical protection: Electronic protection against short circuit
● Rigging protection: with safety chain through bolt at the bottom
RIGGING & MOUNTING
● Rigging: 2pcs omega brackets with 1/4-turn quick fasteners
● Mounting: Four strong feet for better and stable flat placement
ENVIRONMENT AND PHYSICAL
● IP rating: IP20
● Environment temperature: -20°C-40°C
● Dimensions(mm): W395 x D322 x H510
● Net weight: 16.1kg
ACCESSORIES
● Power input cable: 1.0mm2, PVC sheath, length 1.0mtr
● DMX cable: included, length 2.0mtr
● Hanging omega bracket: included (2pcs/pair)
● Safety cable: included, length 0.8mtr
MHB-200A1(OSRAM)B
Moving Head Beam, 200W(5R), OSRAM, IP20, Black Shell
