Light Source:
280W Yodn 10R
2,200 Hour average lamp life
Beam Angle:
prism rotating Zoom: parallel beam angel 2.5°-20° change
Optics
Lens : high precision optical lens
Zoom: parallel beam angel 2.5°-20° change
Colors
Color wheel: 13 dichroic filters + white
Gobos
Rotating Gobo Wheel, with 9 bidirectional and indexable gobos (outside diameter: 15,4 mm, image diameter: 13 mm)
Static Gobo wheel with 14 fixed gobos, at variable rotation
Prism
Prism 1: 8-facet circular prism rotating in both directions at different speeds
Prism 2: 6-facet linear prism rotating in both directions at different speeds
Control
Control mode : Standard DMX512, Automatic and Master/ slave mode
Channel : 16 CHs / 24 CHs
Controller can open the lamp and reset, including delaying function
Effects
Wash effect : adjustable Wash effects angle
Focus: linear adjustment
Dimmer : 0-100% linear adjustment
Strobe : Double lens strobe (0.5-9 times/ second)
8 / 16 Bit resolution adjustable movement
Movement
Pan/Tilt : X axis 540° Y axis 270°automatically accurate positioning
Fixation option: Pan/Tilt-lock mechanism
Connectors
5pin DMX Art-net or 3pin DMX Art-net
powerCon In
Power
100 – 240 VAC, 50/60 Hz
Power Consumption
470 W max.
Operating Temperature
13 to 113°F (-25 to 45°C)
Approvals and Ratings
CE pending
IP20 rated
Working Position
Any
Dimensions
15.2 x 14.4 x 23.2″ (386 x 365 x 589 mm)
Weight
42 lb (19 kg)
