ELECTRICAL
▪ Power supply: Electronic auto-ranging
▪ Color Temperature : 2500～10000K
▪ Beam Angle: 13° – 52°
▪ Power consumption: 1650W
OPTICS
▪ Light Source: 61X30W RGBW 4IN1, 107X0.2W RGB LED
▪ Drive Mode: Constant Current
COLOR SYSTEM
▪ Color Mixing: RGBW 4in1
▪ Uniform RGBW color mixing system and rainbow effect
▪ White balance can be adjusted manually
DYNAMIC EFFECTS
▪ Pan : 540° + 16-bit fine
▪ Tiit : 250° + 16-bit fine
▪ Dimmer: Electronic
▪ Shutter/Strobe: Electronic
▪ Zoom: Motorized
▪ Strobe Rate: 0-25Hz
▪ Color Temperature Presets: Yes
▪ Dim Curves: 4
CONSTRUCTION / PHYSICAL
▪ Dimensions: 4960*2920*5909mm
▪ Weight (single unit):23.7kgs
▪ Exterior Color: Black
▪ Housing Material: die-casting aluminum
▪ Display: OLED
CONNECTIONS
▪ Power In/Out: Powercon
▪ Cable Length (power): 1M
▪ Signal Connection: 3-pin (5-pin optional)
CONTROL
▪ Control Protocol: DMX512,Artnet,Sound-actived,Auto,Master/slave
▪ DMX Channels: 21/49/204/232/265CH
COOLING SYSTEM
▪ Cooling: forced air convection, with slient fan,fans’ speeds adjustable
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
SAFETY DEVICES
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
QUALIFICATIONS
▪ IP Rating: IP20 (indoor use)
WHAT’S INCLUDED
▪ Power cable 1 pc
▪ Signal cable 1pc
▪ Hanging omega bracket included (2pcs/pair)
▪ Safety cable included
OPTIONAL ACCESSORIES
▪ Clamps
▪ Flightcase
