ELECTRICAL
▪ AC power: 100-240 V nominal, 50/60 Hz
▪ Typical total power consumption: 500W
OPTICS
▪ Light source: 20x20W RGBW LEDs (Beam), 20x4W RGBA LEDs (Dot), 144x1W CW WW LEDs (Strobe)
▪ Minimum LED lifetime: 50 000 hours (to >70% luminous output)
▪ Beam angle：6 °, 10 °, 20 °, 40 ° optional (Beam), 120 ° (Dot)
DYNAMIC EFFECTS
▪ RGBW infinite color mixing
▪ Main light source LED divide20 dots control which can createmore dazzling chasing effects
▪ Small dots LED divide 20 dots control，which can create more dazzling chasing
▪ Strobe LED has 19 sections，which can create powerful strobe effects.
▪ 0-20HZ strobe、pulse strobe、ramp-up strobe、ramp-down strobe、strobe effect with intervals 5 second to 1 second .
▪ Dimmer :0-100% 16bit dimmer
CONTROL AND PROGRAMMING
▪ Control mode: DMX512、ArtNet、sACN、master-slave
▪ DMX channels: 11/23/35/48/199/201/DMX+Net1/DMX+Net2 CH modes
DISPLAY
▪ 1.3 inch OLED display screen,switchable between English and Chinese
▪ 4 touch buttons
▪ Key lock function can be set to prevent malfunction
▪ The display screen can reversed by 180°，which is suitable for installation in different positions
CONSTRUCTION
▪ Housing: Die-cast aluminum
▪ Housing surface: baking finished treatment
▪ Color(s): black (white optional)
▪ Protection rating: IP65
INSTALLATION
▪ Mounting: 2pcs bracket, surface for truss mount
▪ Bottom mount for safety wire
▪ Orientation: Any
▪ Location: Outdoor
CONNECTIONS
▪ AC power in/thru: waterproof powerCON
▪ DMX data in/thru: 3-pin XLR (5-pin XLR Optional)
THERMAL
▪ Cooling: silent fan (no noise)
▪ LED temperature detection system to protect the service life of LED chip
▪ Fan heat dissipation (the fan speed changes as per the LED temperature change)
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): -20° C
PHYSICAL
▪ Length: 1014 mm
▪ Width: 146 mm
▪ Height: 104 mm
▪ Weight: 13.0 kg
ACCESSORIES
▪ Power Input cable: included
▪ DMX Cable: included
▪ Safety cable: not included (optional)
